Features
Wide range of operating wavelengths
High reliability and Good stability
Good temperature adaptability
Low noise figure
Support customization
Applications
1310/1490/1550 Optical amplification
High-speed optical communication system
Nonlinear Studies
Space Optical Communication System
Standards
Telcordia GR-1312-CORE
ROHS
Parameter | Unit | Min | Typ. | Max. | Note | |||
C band | nm | 1530 | 1550 | 1570 | ||||
Operating | S band | nm | 1470 | 1490 | 1510 | |||
Wavelength | ||||||||
O band | nm | 1290 | 1310 | 1330 | ||||
Input Power | dBm | -20 | -15 | - | ||||
Output Power | dBm | - | 6 | - | ||||
Gain | dB | 15 | - | - | ||||
Noise Figure | dB | - | - | 7.5 | ||||
Output Power Stability | dB | - | ±0.1 | ±0.2 | ||||
Input isolation | dB | 40 | - | - | ||||
Output isolation | dB | 40 | - | - | ||||
PDG | dB | - | - | 1 | ||||
PMD | ps | - | - | 0.5 | ||||
