Supports automatic EPON/GPON mode switching
Support HGU function
Supports PPPoe/DHCP/static IP routing mode and bridge mode
Supports IPV4 and IPV6 dual mode
Support 2.4G/5.8G dual-band WIFI with multi-SSID function
Supports LAN IP and DHCP Server configuration
Supports port mapping and loop detection
Support 4*10/100/1000M network adaptive
Support firewall function and ACL function
Supports IGMP Snooping/Proxy multicast features
Supports TR069 remote configuration and maintenance
Support one way CATV RF radio frequency (optional)
Item | Type | Technical Parameters |
PON | Interface Type | No CATV: SC/UPC With CATV: SC/APC |
receiver sensitivity | ≤-27dBm | |
luminous power | +1~+4dBm | |
transmission distance | 20KM | |
operating wavelength | TX: 1310nm RX: 1490nm | |
CATV | center wavelength | 1550nm |
Input optical power | +2~-15dBm | |
Optical reflection loss | ＞45dBm | |
frequency range | 47-1006MHz | |
flatness | ±1 dBm (47-1006 MHz) | |
output level | ≥80dBuv(0~-12dB) | |
Output Impedance | 75Ω | |
AGC | 0~-12dBm | |
Carrier-to-noise ratio | ≥51dB | |
CTB | ≥65dB | |
CSO | ≥62dB | |
LAN | Interface Type | 4 Gigabit RJ45 ports |
transfer mode | 10/100/1000Mbps Adaptive | |
Wi-Fi | protocols | IEEE802.11a/b/g/n/ac |
2.4G operating frequency | 2.400-2.4835 GHz | |
5G operating frequency | 5.150-5.825 GHz | |
2.4G External Antenna | 2*2MIMO,300Mbps | |
5G External Antenna | 2*2MIMO,867Mbps | |
Number of antennas | 4 x 5dB high gain antennas | |
(sth. or sb) else | Multi-SSID support | |
Power supply related | connector | DC005 φ2.1mm |
input voltage | 12V1.5A | |
Rated power consumption | ≤7W | |
Environment-related | operating temperature | 0~+50°C |
Operating humidity | 10~85% (non-condensing) | |
Storage temperature | -30~+60℃ | |
Size Weight | Product Size | 200*150*31mm |
Package Size | 275*245*40mm | |
Net Weight | 0.4KG | |
total weight | 0.6KG |
