OEM customized services can be provided according to customer requirements.
Low noise and low power consumption.
Wide operating wavelength range.
Standard RJ-45 network management interface, in line with SNMP standard protocol.
High stability and high reliability.
High-precision AGC and ATC circuits.
Flexible mechanical and circuit structure.
Parameter | symbol | Min | Typ | Max | Unit | |
Wavelength | λ c | 1528 | 1550 | 1562 | nm | |
Output Power | Po | -- | -- | 24 | dBm | |
Input Power | BA | Pi | -14 | -- | +6 | dBm |
LA | -25 | -- | -10 | dBm | ||
PA | -35 | -- | -10 | dBm | ||
Gain | G | -- | 20 | 33 | dB | |
Noise Figure (2) | NF | -- | 5.0 | -- | dB | |
Output Power Stability | Δ Po | -- | ±0.05 | ±0.1 | dB | |
Return Loss | RL | 40 | -- | -- | dB | |
Polarization Dependent Gain | PDG | -- | -- | 0.5 | dB | |
Polarization Mode Dispersion | PMD | -- | -- | 0.5 | ps | |
Operating Temperature | T | -5 | -- | 55 | ℃ | |
Relative Humidity (non-condensing) | RH | 5 | -- | 95 | % | |
