10GBASE-SR at 10.3125Gbps & 10GBASE-SW at 9.95328Gbps
FC-10GFC (8G/10G)
Other optical links
Optical and Electrical Characteristics
Parameter | Symbol | Min. | Typical | Max. | Unit | Notes |
Transmitte Characteristics | ||||||
Center Wavelength Range | λc | 840 | 850 | 860 | nm | |
Spectral Width | Δλ | 0.45 | nm | |||
Launch Optical Power | Pout | -7.3 | -1 | dBm | 1 | |
Extinction Ratio | EX | 3 | dB | |||
Relative intensity noise | RIN12OMA | -128 | dB/Hz | |||
Eye Diagram | Complies with IEEE802.3ae eye masks when filtered | |||||
Receiver Characteristics | ||||||
Receiver Sensitivity | S | -12 | dBm | 2 | ||
Receiver Overload | PIN | -1 | dBm | |||
Signal Detect- Deasserted | LOS-A | -30 | dBm | |||
Signal Detect- Asserted | LOS-D | -12 | dBm | |||
Signal Detect-Hysteresis | 0.5 | 3 | 5 | dB | ||
