l Comply fully with itu-g.984.1/2/3/4 standard and g.987.3 protocol
l Support downlink 2.488 gbits/s rate and uplink 1.244 gbits/s rate
l Upport bidirectional fec and rs(255,239) fec codec
l Support 32 tcont and 32 gemport
l Support aes128 decryption function of g.984 standard
l Support sba and dba dynamically broadband allocation
l Support the ploam function of g.984 standard
l Support dying-gasp check and report
l Support synchronous ethernet
l Good interworking with the olt from different manufacturers，such as huawei ,zte,cortina etc
l Down-link lan ports: 4*10/100/1000m with auto-negotiation
l Support the rogue onu alarm function
l Support vlan function
l Operation mode: Hgu
l Support ieee802.11b/g/n and ieee802.11ac standard for wifi
l Antennas gain: 5dbi with external
l Support: 300mbps phy rate ieee802.11n, 866mbps phy rate ieee802.11ac
l Support multiply ssid
l Multiple encryption methods:Wfa、wpa、wpa2、wapi
l One port for voip，support sip protocol optional
l Comply fully with ieee802.3ah standard and ctc-3.0 specification
l One rf port for tv application
| Tech parameters | description |
| Up-link interface(XPON use the GPON spec) | 1 GPON interface，SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s rate Fiber type：SC/APC Optical power：0~4 dBm Sensitivity：-28 dBm safety: ONU authentication mechanism |
| Wavelength(nm) | TX 1310nm，RX 1490nm |
| Fiber connector | SC/UPC or SC/APC connector |
| Down-link data interface | 4*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface |
| Indicator LED | 10 pcs，refer to NO.6 definition of indicator LED |
| DC supply interface | input＋12V 1A，footprint：DC0005 ø2.1MM |
| Power | ≤7W |
| Operating temperature | -5～+55℃ |
| Humidity | 10～85%（non-condensation） |
| Storage temperature | -30～+70℃ |
| Dimension（MM） | 185*125*32mm（mainframe） |
| Weight | 0.5Kg（mainframe） |
