GZ0000-M1 GPON/EPON ONU 1GE Gigabit Ethernet Optical Network Unit with ZTE Chip for FTTH

• Alternative Names: GPON ONU, EPON ONU, 1GE ONU, Gigabit ONU, FTTH ONU, PON User Terminal, Single Port Optical Network Unit
• Main Applications: FTTH residential broadband, FTTO office access, security monitoring, smart home networking
• Core Highlights: ZTE chipset, dual GPON/EPON mode, 20km transmission, ≤5W ultra-low power, HGU gateway support

The GZ0000-M1 series is a high-reliability, cost-effective Optical Network Unit (ONU) specially designed for Passive Optical Network (PON) systems. As the core user-side equipment in PON architecture, it completes bidirectional conversion between optical signals and Ethernet frames: receiving downstream optical signals and converting them into Ethernet frames for end users, while converting upstream Ethernet frames from user devices into optical signals for transmission to the upper-layer OLT.

Adopting industry-proven ZTE chipset and advanced PON technology, this 1GE ONU significantly outperforms traditional copper access products in cost performance, maintainability and scalability. It natively supports both GPON and EPON network modes, making it fully compatible with mainstream OLT equipment from major vendors and enabling flexible deployment in different network environments. Equipped with 1 Gigabit Ethernet RJ45 port with 10/100/1000Mbps adaptive transmission, it perfectly meets the high-bandwidth demands of HD video streaming, online gaming, high-speed internet access and IP camera monitoring.

With an ultra-compact size of 902116mm and light weight of only 80g, the GZ0000-M1 saves valuable installation space and is easy to deploy in various indoor scenarios. Its rated power consumption is ≤5W, which greatly reduces long-term operating costs and energy consumption. The device supports comprehensive network functions including HGU gateway, IPv4 protocol stack, DHCP Client/Server, PPPoE dial-up, NAT, DMZ, port mapping, loop detection, firewall, ACL and IGMP Snooping/Proxy, ensuring secure, stable and efficient network operation. It can work stably in harsh environments with an operating temperature range of 0~+50℃ and humidity of 10~85% (non-condensing), and supports a maximum transmission distance of 20km, making it an ideal choice for large-scale FTTH/FTTO construction.

• Fiber to the Home (FTTH) residential broadband access
• Fiber to the Office (FTTO) small and medium-sized enterprise network access
• Security monitoring system (IP camera, NVR remote access)
• Smart home and IoT device network connection
• Campus and community broadband network construction
• Remote area and rural fiber broadband coverage

1. Dual-mode Compatibility: Seamlessly support both GPON and EPON networks, compatible with all mainstream OLT brands, no need to replace equipment when upgrading networks
2. High-performance Chipset: Adopt original ZTE chip, stable operation, strong anti-interference ability, long service life
3. Ultra-low Power Consumption: ≤5W rated power, energy-saving and environmentally friendly, reducing annual electricity costs by more than 60% compared with similar products
4. Miniature Design: Ultra-compact size and light weight, easy to install on walls, desktops or distribution boxes, saving installation space
5. Comprehensive Security: Built-in firewall and ACL access control, effectively preventing network attacks and ensuring user data security
6. Cost-effective: Excellent performance at a competitive price, ideal for large-scale batch deployment in operator projects
7. Easy Maintenance: Plug-and-play design, support remote management, reducing on-site maintenance costs
